0.0180" 0.45mm Diam. Ball Nose End Mill, Carbide, AlTiN Coated, 4 Flute, 1835-0180L027 K103
0.0180" 0.45mm Diam. Ball Nose End Mill, Carbide, AlTiN Coated, 4 Flute, 1835-0180L027 K103
Regular price
$19.95 USD
Regular price
Sale price
$19.95 USD
Unit price
per
8 left in stock
SKU: K103
Couldn't load pickup availability
| Hardened (H) Compatibility: Yes | End Mill Application: Roughing/Finishing |
| Helix Angle: 30 Degrees | Finish: AlTiN |
| Milling Dia.: 0.0180" | End Mill Style: Ball Nose |
| Shank Type: Straight | Steel (P) Compatibility: Yes |
| List Number: 1835 | Cutting Direction: Right Hand |
| Number of Flutes: 4 | Cast Iron (K) Compatibility: Yes |
| Shank Dia.: 0.1250" | Non Ferrous (N) Compatibility: No |
| Item: Ball End Mill | Stainless (M) Compatibility: Yes |
| End Mill Material: Carbide | Grade: Micro Grain |
| Milling Diameter: 0.0180" | End Mill Cutting Type: Center Cutting |
| Dimension Type: Decimal inch | Overall Length: 1.5000" |
| Length of Cut: 0.0270" | Super Alloy (S) Compatibility: Yes |
| Single End/Double End: Single End | Finish - Machining: AlTiN |
| Material Grade - Machining: Micro Grain | Country of Origin (subject to change): United States |
